A temperature sensor is a device that detects and measures hotness and coolness and converts it into an electrical signal. THERMPRO temperature sensors include RTDs, platinum temperature sensors, NTC/PTC thermistors, NTC temperature sensors, probes and assemblies.
The battery temperature sensor is applicable to temperature control module of lithium battery. Different terminals and cables are available for flexibility in applications.
The NTC temperature sensor for temperature measurement and control of household/automobile air conditioner, refrigerator, freezer, water heater, water dispenser, fan heater, dishwasher, disinfector, washing machine, drying machine, middle/low-temperature drying oven, incubator and so on.
Power NTC Thermistor MF72 provides inrush current suppression for sensitive electronics. Connecting a MF72 in series with the power source will limit the current surges typically created at turn on. Once the circuit is energized the resistance of the MF72 will decrease rapidly to a very low value, power consumption can be ignored and there will be no effect on normal operating current. MF72 provides a most cost-effective way to curb surge current and protect sensitive electronics from damage.
The high precision NTC thermistor MF51E is for extremely accurate temperature measurement. It is specially designed for use in electronic thermometers which require better than average accuracy. The extremely small size allows the thermistor to respond very quickly to tiny changes in temperature. The MF51E can be supplied un-calibrated with standard tolerances or calibrated and grouped according to R at 37°C±0.01% for extreme interchangeability so as to eliminate the need for other calibrations.
The ethoxyline resin coated NTC thermistor is for temperature measurement. It provides the benefit of close tolerances and fast response.
Mz6 Type PTC Thermistor is widely used for over temperature protection on the main parts inside the electric motor. For example, the PTC thermistor is embedded into the three-phase electric motor stator winding. When the temperature of stator winding of electric motor is up to the insulation grade temperature of insulated material, the resistance of PTC thermistor will rise at the same time. And the signal is transmitted to the protector to switch off the current of electric motor and finally prevent the electric motor from being burned out.
 |
